RS1 "microdrive" Copy Stand

SKU: 205507 | FREE U.S. shipping on all orders over $50!

$1,187.50
  • Non-reflective matte gray base board with printed fine grid. Feet adjustable in height. Spirit level in column base.
  • Extra-wide and extremely vibration-resistant column of matte black anodized aluminum tubing with inch/cm scale
  • Hand-cranked, rack-and-pinion height adjustment, additionally counter-balanced by a built-in oll-off spring mechanism for weight compensation
  • Additional fine drive with 1:6 step-down transmission for super-fine adjustment. Locking screw prevents inadvertent changing of the adjusted height.
  • Especially useful for high magnigication macro photography that requires very precise movement of the camera on the column.

Overview

Especially useful for high magnigication macro photography that requires very precise movement of the camera on the column.

Specifications

Base Board Dimensions (in):
19.7x17.7x1.0
Base Board Dimensions (mm):
500x450x27
Base Board Type:
Gridded, non-reflective, matte gray
Bushing Thread Mount (in):
1/4"-20, 3/8"-15
Camera Arm Type:
RA 1 Camera Arm
Column Cross Section (in):
2.8
Column Cross Section (mm):
70
Column Height (in):
39.4
Column Height (cm):
100
Maximum Payload Capacity (lb):
8.8
Maximum Payload Capacity (kg):
4
Original Width for focal length (in/cm) 100 mm:
10.6/26
Original Width for focal length (in/cm) 50 mm:
20.9/52
Product Height (in):
1
Product Height (cm):
40.55
Product Length (cm):
0.01
Product Weight (lb):
40.55
Product Weight (kg):
103
Warranty:
2 Year
